Hey Everybody! I just bought my first MGB, a 76 model. Brought it home, went to open the hood, found the safety latch, but not the release cable!!!!!!! Where is it???? The only "handles" under the dash are what seems to be the air vent control, and to the left of that, a small black round knob that doesn't turn or pull!

Are there any pics of the switches/ controls and functions?

Thanks in advance,

Mike

Should be under the dash, way to the left, about where your left knee would be.

---

Brian Lundgren
Central Texas
'79 B with wires and OD
'75 Yeller B

I always wanted to be a procrastinator, but never got around to it! :beer:

Look under the dash on the left side of the steering wheel, close to the door.

It should be on the far left, well back under the dash. You pull it straight out. It should have a black handle on it. I've posted a picture in a later post.

How could you get to the safety catch if you couldn't get the hood open?

---

John English
1976 MGB
HIF44 carb on late manifold, Schlemmerized 45D w/Pertronix, Limey's relay kit, solid state voltage stabilizer.


Luke 1:37



Edited 1 time(s). Last edit at 2007-11-17 11:27 PM by jdeluke137.

By the way - welcome aboard!

You may already know this, but if you're anywhere close to Clemson you've got a great parts supplier there - Gordon at the B Hive. Here's a link to his website:

http://bhive.tierranet.com/intro.htm

---

John English
1976 MGB
HIF44 carb on late manifold, Schlemmerized 45D w/Pertronix, Limey's relay kit, solid state voltage stabilizer.


Luke 1:37



Edited 1 time(s). Last edit at 2007-11-17 11:09 PM by jdeluke137.

Knob with a B on it. This is a 67B but all have the bonnet release in the same place, unless its a right hand drive.

---

Lee Miller

Experience - hobbyist, rotisserie restoration 1967 MGB, welding, bodywork, painting, wiring, interior, suspension, clutch, engine, SU HS4 carburetors, windshield, and installing convertible top.

Website www.myclassicmg.com

1971 MG MGB
1971 MG Midget
1967 MG MGB
1966 MG MGB restoration project

Picture of knob from a 76B.

---

John English
1976 MGB
HIF44 carb on late manifold, Schlemmerized 45D w/Pertronix, Limey's relay kit, solid state voltage stabilizer.


Luke 1:37

For the record, the things on the right of the column are the lever that pulls the fresh air door open and the trip odometer reset. Turn the reset knob one way or another to reset the numerals on the speedo head. Sometimes you have to pull or push the knob to get it to engage.

Welcome aboard. This NC/SC/GA area is a hot bead of LBC (Little British Car) folks and they are all good folks. Check in here as often as you can and ask any questions that come to mind. BTW: There are no more dumb questions so don't be bashful. We have already asked the dumbest ones. LOL

Unless you are already some sort of gear head, be prepared to become at least a slight one. A lot of enjoyment of these cars is knowing how they tick. You don't have to do all of you own work but understanding what is going on in various departments helps make your ownership more pleasant. If you didn't get books with the car I would suggest that you dig up an original owner's hand book at least and at best start your library with what is called The Bentley manual. The one for your car has a red cover and includes all of the rubber bumper cars from late 74 through the end of production in 80. Amazon and other literature sites will have both.

Also, go out to the car and take a note or two. Jot down the serial number and production date. That will be on a plate in the driver's door jamb. The go to the passenger side of the engine and about half way down in the middle where the head meets the block the should be a narrow riveted on plate with a sequence of numbers and letters beginning with 18V***. Get that info and come back to you computer and reset that information in your member profile so that it shows up under your name and where you live when you place a post. Add your city of residence too. All of that will help greatly when someone wants to respond to your questions as they will know right off the bat what model and equipment you have on the car.

Jack

---

--------------------------------------- Services to Interesting British Automobiles-----------------------------------
----------------------------------------------------www.jackscars.net ----------------------------------------------------

-------------I like to think that I don't service automobiles so much as I provide entertainment, fulfill dreams and revive wonderful memories --------------

I am in the northwestern North Carolina mountains, right up against the Blue Ridge Parkway. Lawn chairs are in the shop and always time to talk. Drop in any time.



Edited 1 time(s). Last edit at 2007-11-18 06:13 AM by twigworker.

The B is missing on my knob, but here's a pic. Also the location of the voltage stabilzer for the temp and gas gauge. That's a whole different subject for later.

Looks like coathanger fun time!
After you get the hood open order a secondary bonnet release from Gerry. On second thought, check under the left fender for a release.

Nice-car.



Edited 1 time(s). Last edit at 2007-11-18 09:17 AM by ClayJ.

Maybe you have one of those handy dandy jerry-rigged releases that come out in the driver's side wheel well. Is there a wire, with a handle, ahead of and above the wheel/tire?

sailadams Wrote:
Ya can get a "Professional One" from our own Gerry and it's GREAT!!!

---

"1964 MGB" (Kirby) All original pull handle MGB, 3 main, with overdrive, but a daily driver with all the dents and dings to prove it -- Titled in 1965~~

"1980 MGB" (Robbie) Even though it's a RB it does have overdrive, a Weber Carb, and is my favorite MGB. We have logged thousands of happy miles together ~~

That's the one I meant. Gerry not Jerry.

Hiya Peter,

Great Dash. Has anyone else painted their dashes a smooth gloss to match their body color or something similar?

Pat

Okay - where's nite53. I want to know if he ever got his hood open.

---
